How to Build AJAX Post Filtering in WordPress with WP_Query

Why AJAX Filtering?

When a site has dozens or hundreds of posts — portfolio projects, job listings, products, articles — visitors need a way to narrow down what they see. The traditional approach reloads the entire page for every filter click, which feels slow and clunky.

AJAX filtering solves this. The user clicks a filter, JavaScript sends a background request to the server, WordPress runs a fresh WP_Query, and only the results section updates — no full page reload. The experience is instant and modern.

This guide builds a complete AJAX filtering system from scratch for a custom post type, using the native WordPress AJAX API and vanilla JavaScript — no jQuery, no plugins.

---

How WordPress AJAX Works

WordPress routes all AJAX requests through a single endpoint: wp-admin/admin-ajax.php. You register a server-side handler function and hook it to a custom action name. The front end sends a request specifying that action, and WordPress calls your handler.

There are two hooks for every action:

• wp_ajax_{action} — fires for logged-in users
• wp_ajax_nopriv_{action} — fires for logged-out (public) visitors

For a public-facing filter, you need both — otherwise the filter works for you while logged into the admin but silently fails for regular visitors. This is the single most common mistake when building AJAX features in WordPress.

---

Step 1: Enqueue the Script and Pass Data

First, enqueue your JavaScript file and use wp_localize_script() to pass the AJAX URL and a security nonce into the script. The nonce protects the endpoint against unauthorized requests.

function orbit_enqueue_filter_assets() {
    wp_enqueue_script(
        'orbit-filter',
        get_template_directory_uri() . '/assets/js/filter.js',
        array(),
        '1.0.0',
        true
    );

    wp_localize_script( 'orbit-filter', 'orbitFilter', array(
        'ajax_url' => admin_url( 'admin-ajax.php' ),
        'nonce'    => wp_create_nonce( 'orbit_filter_nonce' ),
    ) );
}
add_action( 'wp_enqueue_scripts', 'orbit_enqueue_filter_assets' );

The orbitFilter object is now available globally in filter.js, giving the script the endpoint URL and nonce it needs.

---

Step 2: Build the Filter UI

Output the filter buttons dynamically from your taxonomy terms, plus a container that will hold the results. In your template file (e.g., archive-project.php):

<div class="filter-bar">
    <button class="filter-btn active" data-term="all">All</button>

    <?php
    $terms = get_terms( array(
        'taxonomy'   => 'industry',
        'hide_empty' => true,
    ) );

    foreach ( $terms as $term ) :
    ?>
        <button class="filter-btn" data-term="<?php echo esc_attr( $term->slug ); ?>">
            <?php echo esc_html( $term->name ); ?>
        </button>
    <?php endforeach; ?>
</div>

<div id="filter-results">
    <?php
    // initial unfiltered load handled by the main query loop
    get_template_part( 'template-parts/project', 'grid' );
    ?>
</div>

Each button stores its taxonomy term slug in a data-term attribute. The "All" button uses all as a sentinel value to clear the filter.

---

Step 3: Create a Reusable Results Template

Move the post card markup into its own template part so both the initial PHP load and the AJAX response render results identically. Create template-parts/project-grid.php:

<?php
$query = isset( $filtered_query ) ? $filtered_query : $wp_query;

if ( $query->have_posts() ) :
    echo '<div class="project-grid">';

    while ( $query->have_posts() ) : $query->the_post();
    ?>
        <article class="project-card">
            <a href="<?php the_permalink(); ?>">
                <?php if ( has_post_thumbnail() ) : ?>
                    <div class="project-thumb">
                        <?php the_post_thumbnail( 'medium_large' ); ?>
                    </div>
                <?php endif; ?>
                <h3><?php the_title(); ?></h3>
                <p><?php echo esc_html( get_the_excerpt() ); ?></p>
            </a>
        </article>
    <?php
    endwhile;

    echo '</div>';

    wp_reset_postdata();
else :
    echo '<p class="no-results">No projects found.</p>';
endif;

Using a shared template part guarantees the markup is consistent whether posts are rendered on first load or after an AJAX filter — no duplicated HTML, no drift between the two.

---

Step 4: Write the Server-Side AJAX Handler

This is the core. The handler verifies the nonce, reads the requested term, builds a WP_Query with a tax_query when a specific term is requested, renders the template part, and returns the HTML.

function orbit_filter_projects() {

    // Verify the nonce for security
    check_ajax_referer( 'orbit_filter_nonce', 'nonce' );

    $term = isset( $_POST['term'] ) ? sanitize_text_field( $_POST['term'] ) : 'all';

    $args = array(
        'post_type'      => 'project',
        'posts_per_page' => 9,
        'orderby'        => 'date',
        'order'          => 'DESC',
    );

    // Only add a tax_query if a specific term was requested
    if ( $term !== 'all' ) {
        $args['tax_query'] = array(
            array(
                'taxonomy' => 'industry',
                'field'    => 'slug',
                'terms'    => $term,
            ),
        );
    }

    $filtered_query = new WP_Query( $args );

    // Capture the template output into a string
    ob_start();
    set_query_var( 'filtered_query', $filtered_query );
    get_template_part( 'template-parts/project', 'grid' );
    $html = ob_get_clean();

    wp_send_json_success( array( 'html' => $html ) );
}
add_action( 'wp_ajax_orbit_filter_projects', 'orbit_filter_projects' );
add_action( 'wp_ajax_nopriv_orbit_filter_projects', 'orbit_filter_projects' );

Key points in this handler:

• check_ajax_referer() validates the nonce — if it fails, the request dies immediately.
• Output buffering (ob_start() / ob_get_clean()) captures the rendered template part into a string instead of echoing it.
• set_query_var() passes the custom query into the template part so it uses the filtered results.
• wp_send_json_success() returns a clean JSON response and handles the correct headers and wp_die() automatically.
• Both hooks are registered — logged-in and public — so the filter works for everyone.

---

Step 5: The Front-End JavaScript

Now wire up filter.js with vanilla JavaScript using the Fetch API. No jQuery required.

document.addEventListener('DOMContentLoaded', function () {

    const buttons = document.querySelectorAll('.filter-btn');
    const results = document.getElementById('filter-results');

    buttons.forEach(function (button) {
        button.addEventListener('click', function () {

            // Update active button state
            buttons.forEach(b => b.classList.remove('active'));
            button.classList.add('active');

            const term = button.getAttribute('data-term');

            // Show a loading state
            results.classList.add('loading');

            // Build the request payload
            const formData = new FormData();
            formData.append('action', 'orbit_filter_projects');
            formData.append('nonce', orbitFilter.nonce);
            formData.append('term', term);

            fetch(orbitFilter.ajax_url, {
                method: 'POST',
                body: formData,
            })
            .then(response => response.json())
            .then(data => {
                if (data.success) {
                    results.innerHTML = data.data.html;
                }
                results.classList.remove('loading');
            })
            .catch(error => {
                console.error('Filter error:', error);
                results.classList.remove('loading');
            });

        });
    });

});

The flow: a click updates the active button, shows a loading state, sends a FormData POST to admin-ajax.php with the action, nonce, and term, then swaps the results HTML with the server response.

---

Step 6: Add a Loading State with CSS

A small visual cue during the request makes the interaction feel responsive. A simple fade works well:

#filter-results {
    transition: opacity 0.2s ease;
}

#filter-results.loading {
    opacity: 0.4;
    pointer-events: none;
}

.filter-btn {
    cursor: pointer;
    transition: all 0.2s ease;
}

.filter-btn.active {
    background: #0066FF;
    color: #fff;
}

---

Handling Multiple Filters at Once

To filter by multiple taxonomies simultaneously — say, industry and project type — collect all active filter values on the front end and pass them as separate parameters. Then build a multi-clause tax_query server-side:

$tax_query = array( 'relation' => 'AND' );

if ( ! empty( $_POST['industry'] ) && $_POST['industry'] !== 'all' ) {
    $tax_query[] = array(
        'taxonomy' => 'industry',
        'field'    => 'slug',
        'terms'    => sanitize_text_field( $_POST['industry'] ),
    );
}

if ( ! empty( $_POST['project_type'] ) && $_POST['project_type'] !== 'all' ) {
    $tax_query[] = array(
        'taxonomy' => 'project_type',
        'field'    => 'slug',
        'terms'    => sanitize_text_field( $_POST['project_type'] ),
    );
}

if ( count( $tax_query ) > 1 ) {
    $args['tax_query'] = $tax_query;
}

The 'relation' => 'AND' ensures posts must match every active filter. Switch to 'OR' if you want posts matching any selected filter instead.

---

Adding AJAX Pagination (Load More)

The same pattern extends to a "Load More" button. Pass a paged value from the front end, increment it on each click, and append the new results instead of replacing them:

// Server-side: add paged to the query args
$paged = isset( $_POST['page'] ) ? absint( $_POST['page'] ) : 1;
$args['paged'] = $paged;

// Front-end: append instead of replace
results.insertAdjacentHTML('beforeend', data.data.html);

Track the current page in a JavaScript variable, and hide the Load More button when $filtered_query->max_num_pages is reached — pass that value back in the JSON response so the front end knows when to stop.

---

Security Checklist

• Always verify the nonce with check_ajax_referer() — never trust an unauthenticated request.
• Sanitize every input — sanitize_text_field() for strings, absint() for numbers, before they touch the query.
• Register both wp_ajax_ and wp_ajax_nopriv_ hooks for public filters.
• Never pass raw user input into a query without sanitization — even though WP_Query parameterizes values, sanitizing is a non-negotiable habit.
• Escape all output in the template part with esc_html(), esc_url(), and esc_attr().

---

Final Thoughts

AJAX filtering with WP_Query is a foundational front-end pattern that applies to portfolios, job boards, product catalogs, blog archives, and directory sites. Once you understand the flow — enqueue and localize, build the UI, handle the request server-side with output buffering, and swap the HTML on the front end — you can adapt it to almost any dynamic listing requirement.

Because it uses the native WordPress AJAX API and a shared template part, the result is clean, maintainable, and plugin-free. The same architecture scales from a simple three-button filter to a full multi-taxonomy faceted search with pagination.

In the next post, we'll look at optimizing these queries for performance — caching WP_Query results with transients so heavy filtered archives stay fast even under load.
